The causes of tungsten points’ ablation of car distributor can be seen as follows:

3. Car engine working at a low speed during a long period. In case the car engine working at a low speed during a long period, the closure time of tungsten points will prolonged resulting from the decreased frequency of opening and closing, and lead to the increase of  self-induced electromotive force of the primary winding and the primary current, eventually tungsten points will ablate. To avoid these phenomenons, you should increase the tungsten points’ gap of distributor appropriately.

4. Bad capacitor work

Bad internal connection or bad connection between housing and ground will lead to bad capacitor work.
Checking way: using the way of disassembling capacitor to in contrast of high voltage electrical spark.

When you disconnect the power-off tungsten points, capacitor will absorb the surge voltage which is formed by the self-induced electromotive force of primary winding of the ignition coil to reduce spark discharge of tungsten points, and to avoid tungsten points being ablated, furthermore, improving the rate change of primary current, therefore, improving the high-pressure spark.




Tungsten Metals Manufacturer & Supplier: Chinatungsten Online - http://www.tungsten.com.cn
 Tel.: 86 592 5129696; Fax: 86 592 5129797
 Email: sales@chinatungsten.com
 Tungsten & Molybdenum Information Bank: http://i.chinatungsten.com
 Tungsten News & Tungsten Prices, 3G Version: http://3g.chinatungsten.com
 Molybdenum News & Molybdenum Price: http://news.molybdenum.com.cn

The reasons of tungsten contacts ablation of car distributor as follows:

3. Car engine running at low speed for a long time. If the car engine running at low speed for a long time, it will make tungsten contacts closure time prolonged due to the decreasing frequency of opening and closing, resulting in self-induced electromotive force of the primary winding increased and the primary current will also increased, eventually causing tungsten contacts ablation. To avoid the aforementioned phenomenon, tungsten contacts gap of distributor should be appropriately increased.

4. Bad capacitor work

The reason of bad capacitor work is that bad connection between housing and ground or bad internal connection.
Check method: adopting the method of disassembling capacitor to compare high voltage electrical spark.

When power-off tungsten contacts is disconnected, capacitor will absorb the surge voltage which is formed by the self-induced electromotive force of primary winding of the ignition coil to reduce spark discharge of tungsten contacts, so tungsten contacts can avoid being ablated , but also improve the rate of change of primary current, thereby enhancing the high-pressure spark.




Tungsten Metals Manufacturer & Supplier: Chinatungsten Online - http://www.tungsten.com.cn
 Tel.: 86 592 5129696; Fax: 86 592 5129797
 Email: sales@chinatungsten.com
 Tungsten & Molybdenum Information Bank: http://i.chinatungsten.com
 Tungsten News & Tungsten Prices, 3G Version: http://3g.chinatungsten.com
 Molybdenum News & Molybdenum Price: http://news.molybdenum.com.cn

The causes of tungsten points’ ablation of car distributor can be read as follows:

5. The bracket screw or tungsten points’ riveting of the distributor is loose. If tungsten points’ riveting of the distributor is loose, then the engine will break. When the engine operates at high speeds, the exhaust pipes of the engine will shoot. And the gap tungsten contacts will change intensely, sometimes small and sometimes large, which can result in low-voltage current that can not be cut off at some point, and ultimately leading to tungsten points’ ablation.

6. The surface of tungsten points offset or skew. If the surface of tungsten points offset or skew, then the resistance will increase. The primary current will decrease and high speed off the fire will occur when the generator working at high speed. Flashover distance will be shortened when test fire. The spark will flows through the points when the engine is operating, which will make the current centered, therefore, the temperature of the current flowing through the point will rise, bring about the result that tungsten points will ablate eventually.




Tungsten Metals Manufacturer & Supplier: Chinatungsten Online - http://www.tungsten.com.cn
 Tel.: 86 592 5129696; Fax: 86 592 5129797
 Email: sales@chinatungsten.com
 Tungsten & Molybdenum Information Bank: http://i.chinatungsten.com
 Tungsten News & Tungsten Prices, 3G Version: http://3g.chinatungsten.com
 Molybdenum News & Molybdenum Price: http://news.molybdenum.com.cn

The reasons of tungsten contacts ablation of car distributor shown as follows:

5. The riveting of tungsten contacts of the distributor is loose or the bracket screw is loose. If the riveting of tungsten contacts of the distributor is loose, then the engine will fracture. And the engine’s exhaust pipes will shoot when the engine running at high speeds. The gap change of tungsten contacts is intense when the engine running at high speeds, sometimes large and sometimes small, which can cause low-voltage current that can not be cut off at some point, leading tungsten contact ablation eventually.

6. Tungsten contacts’ surface offset or skew. If the tungsten contacts’ surface offset or skew, then, it will lead to the increase of resistance. When the generator running at high speed, the primary current will reduce, high speed off the fire will occur. When test fire, flashover distance will be shortened. When the engine is working, it is the points that spark through, it will make the current focused, so that the temperature of the current through the point will rise, eventually leading to tungsten contact ablation.




Tungsten Metals Manufacturer & Supplier: Chinatungsten Online - http://www.tungsten.com.cn
 Tel.: 86 592 5129696; Fax: 86 592 5129797
 Email: sales@chinatungsten.com
 Tungsten & Molybdenum Information Bank: http://i.chinatungsten.com
 Tungsten News & Tungsten Prices, 3G Version: http://3g.chinatungsten.com
 Molybdenum News & Molybdenum Price: http://news.molybdenum.com.cn

The causes of tungsten points’ ablation of car distributor can be seen as follows:

3. Car engine working at a low speed during a long period. In case the car engine working at a low speed during a long period, the closure time of tungsten points will prolonged resulting from the decreased frequency of opening and closing, and lead to the increase of  self-induced electromotive force of the primary winding and the primary current, eventually tungsten points will ablate. To avoid these phenomenons, you should increase the tungsten points’ gap of distributor appropriately.

4. Bad capacitor work

Bad internal connection or bad connection between housing and ground will lead to bad capacitor work.
Checking way: using the way of disassembling capacitor to in contrast of high voltage electrical spark.

When you disconnect the power-off tungsten points, capacitor will absorb the surge voltage which is formed by the self-induced electromotive force of primary winding of the ignition coil to reduce spark discharge of tungsten points, and to avoid tungsten points being ablated, furthermore, improving the rate change of primary current, therefore, improving the high-pressure spark.




Tungsten Metals Manufacturer & Supplier: Chinatungsten Online - http://www.tungsten.com.cn
 Tel.: 86 592 5129696; Fax: 86 592 5129797
 Email: sales@chinatungsten.com
 Tungsten & Molybdenum Information Bank: http://i.chinatungsten.com
 Tungsten News & Tungsten Prices, 3G Version: http://3g.chinatungsten.com
 Molybdenum News & Molybdenum Price: http://news.molybdenum.com.cn

The reasons of tungsten contacts ablation of car distributor:

1. Tungsten contacts gap is too small. If tungsten contacts gap is too small, it will make the closing time of tungsten contacts extended, resulting in the disconnection of the primary winding and the increase of self-induced electromotive force, eventually the tungsten contacts will ablate due to the spark erosion of tungsten contacts intensified.

2. Battery wire connection is bad. If the battery wire connection is bad, then because the car in moving process will bump and vibrate, which would make the battery wire connection sometimes turned sometimes interrupted, causing the generator will occur briefly overvoltage phenomenon, so that the primary winding of the ignition system of self-induced electromotive force exceed and the primary current increase, leading to the formation of strong spark discharge between tungsten contacts, resulting in tungsten contact ablation.




Tungsten Metals Manufacturer & Supplier: Chinatungsten Online - http://www.tungsten.com.cn
 Tel.: 86 592 5129696; Fax: 86 592 5129797
 Email: sales@chinatungsten.com
 Tungsten & Molybdenum Information Bank: http://i.chinatungsten.com
 Tungsten News & Tungsten Prices, 3G Version: http://3g.chinatungsten.com
 Molybdenum News & Molybdenum Price: http://news.molybdenum.com.cn

The spin-lattice relaxation of the S-state ion Gd3+ in a calcium tungstate host lattice has been examined at 37.5 GHz over the temperature range 1.5 to 30 K. The gadolinium concentrations in the doped single crystals used were about 50 ppm. Single exponential recovery was observed and the spin-lattice relaxation time (T 1) varied from about 14 msec at 1.5 K to 0.03 msec at 30 K, measured with θ=90° and φ=8°. It was found that T 1 varied with temperature (T) as T 1 ∝ T −1 below 8 K and as T 1 ∝ T −3 between 8 and 30 K. The experimental data was fitted by the expressions T 1 −1 =35 T+0.5 T 3 and T 1 −1 =35T+0.1 T 3.6 for crystals of nominal gadolinium concentrations 0.005 wt % and 0.05 wt % respectively. The difference between the observed dependence and the T −5 variation predicted in the Raman region for an S-state ion in a perfect lattice is attributed to defects. Measurements in the φ-plane at 4.2 K showed that T 1 was anisotropic with a maximum value atφ=25° about three times greater than the minimum value obtained at φ=55°. The angular positions at which these features occur show a remarkable coincidence with the “acoustic axes of symmetry” of the crystal, which have recently been determined by ultrasonic methods.


Tungsten Powder Manufacturer & Supplier: Chinatungsten Online -www.tungsten-powder.com
Tel.: 86 592 5129696; Fax: 86 592 5129797
Email: sales@chinatungsten.com
Tungsten & Molybdenum Information Bank: http://i.chinatungsten.com
Tungsten News & Tungsten Prices, 3G Version: http://3g.chinatungsten.com
Molybdenum News & Molybdenum Price: http://news.molybdenum.com.cn

CaWO₄ nanocrystals with average diameters of 20-30 nm and nanorods with mean lengths of 600-1000 nm were controllably synthesized through a facile microemulsion-mediated hydrothermal procedure. And the factors affecting the morphologies of the products, such as the molar ratio ( w) between water and CTAB, the reaction temperature and the concentration of the reactants, were studied and discussed. With the increase of the w value, the diameter of the as-synthesized products increased gradually, except in the case of w=10 where nanorods were formed. With the temperature increasing, the morphologies of the products changed from nanocrystals to nanorods, and finally to nanocrystals again. However, the concentration of the reactants exhibited no obvious influence on the shape and size of the CaWO₄ product. A possible mechanism is proposed for the selective formation of the different morphologies. The photoluminescent properties of the CaWO₄ nanocrystals are also reported. All the products of CaWO₄ with different morphologies exhibited the only green peak at 435 nm with an excitation wavelength at 238 nm.
