Tungsten Carbide Ball Bearing VIII

The maximum capacity or filling slot type radial ball bearings have inner and outer races that are notched so that when they are aligned, additional balls can be slipped into the slot in order to fill the bearing. The advantage of this bearing is that the entire groove is filled with balls.  This is called a full complement/capacity which allows these bearing types to carry increased load ratings.

Although designed to carry primarily radial loads, which are loads perpendicular to the axis of the bearing, the deeper the contour of the rolling track, the greater the ability of the bearing to tolerate thrust loads placed along the axis of the bearing. These bearings are designed for use in high speed, high precision applications for the agriculture, automotive and chemical industries. They are also found in engines, motors, hand tools, fans, etc.

For tariff purposes, radial ball bearings are divided into three types: single row ball bearings, double row ball bearings (bearings having two rolls of balls that revolve around the ball path) and bearings having more than a double row of balls. The single row ball bearings are further broken down into the maximum or full capacity type or the non-filling (Conrad) type. The ten digit classification for the Conrad type bearings is dependent on the outside diameter of the bearing. For tariff purposes, flanges and other projections from the outside surface of the outer race or ring are not included in the measurement of the outside diameter.
